NBS Rubber Abrasion Tester abrasion resistance of rubber and other compounds of sole and shoe heel materials.
model :
AF28Brand:
AVENOorigin:
ChinaLead Time：
10-20daysport:
Xiamen portPayment:
T/T, L/Ccertificate:
CE ISO9001 ISO17025standard:
ASTM-D1630, SATRA TM221AF28 NBS Rubber Abrasion Tester
Application OfNBS Rubber Abrasion Tester
NBS Rubber Abrasion Tester abrasion resistance of rubber and other compounds of sole and shoe heel materials. Users can set the test times according need, if external power outage or stop work, it has memory function, will keep the record. Can connect to dust cleaning equipment, Convenient cleaning.
Standards Of NBS Rubber Abrasion Tester
ASTM-D1630, SATRA TM221
Key Specification Of NBS Rubber Abrasion Tester
|
Model |
AF28 NBS Rubber Abrasion Tester |
|
Test position |
3 |
|
Sample size |
25.4×25.4×6.35mm |
|
Wheel diameter |
∮150 mm |
|
Load |
2265g, 3sets |
|
Sand paper |
Grit ＃40 |
|
Rotary speed |
45±5r/min |
|
Power supply |
AC220V, 50/60HZ |
|
Dimension |
710×440×560mm |
|
Weight |
115kg |
DIN Abrasion Tester is suitable to determine the wear resistance of elastic material, rubber, tires, conveyor belts, shoe soles, soft synthetic leather and other materials.
